| PERFORMANCE |
| Processor |
Intel Core™ i3-1315U, 6C (2P + 4E) / 8T, P-core up to 4.5GHz, E-core up to 3.3GHz, 10MB Intel® Smart Cache
|
| Graphics |
Integrated Intel® UHD Graphics
|
| Chipset |
Intel® SoC Platform
|
| Memory |
1x 16GB SODIMM DDR5-5200
|
| Memory Slots |
Two DDR5 SODIMM slots, dual-channel capable
|
| Max Memory
|
Up to 32GB DDR5-5200
|
| Storage |
512GB SSD M.2 2280 PCIe® 4.0x4 NVMe®
|
| Max Storage Support
|
- Up to three drives, 1x 3.5" HDD + 2x M.2 SSD • 3.5" HDD bay is only for customer self upgrade • M.2 SSD up to 1TB each
- To install a HDD storage, 3.5'' HDD screws, 3.5'' HDD SATA cable and SATA power cable is needed
|
| Card Reader |
No card reader
|
| Optical |
None
|
| Audio Chip |
High Definition (HD) Audio, Realtek® ALC623-CG codec
|
| Speakers |
No speakers
|
| Power Supply |
200W 90%
|
| DESIGN |
| Keyboard |
USB Calliope Keyboard, Black, English
|
| Mouse |
USB Calliope Mouse, Black
|
| Expansion Slots |
- One PCIe® 4.0 x16, full-height, length ≤ 233.6mm, height ≤ 117.5mm
- One PCIe® 3.0 x1, full-height, (length ≤ 185mm, height ≤ 100mm) or (length ≤ 118mm, height ≤ 110mm)
- Three M.2 slots (one for WLAN, two for SSD)
|
| Case Color |
Black
|
| Toolless Chassis Screw |
None
|
| Pen |
Pen Not Supported
|
| Form Factor |
Tower (13.6L)
|
| Dimensions (WxDxH)
|
145 x 290 x 346 mm (5.71 x 11.42 x 13.62 inches)
|
| Weight
|
Around 4.36 kg (9.6 lbs)
|
| CONNECTIVITY |
| WLAN + Bluetooth
|
Intel® Wi-Fi® 6 AX203, 802.11ax 2x2 + BT5.2
|
| WWAN |
WWAN Not Supported
|
| Ethernet |
RTL8111K, 1x RJ-45
|
| Front Ports |
- 1x USB-C® (USB 5Gbps / USB 3.2 Gen 1), with data transfer and 15W charging
- 2x USB-A (USB 5Gbps / USB 3.2 Gen 1)
- 2x USB-A (USB 10Gbps / USB 3.2 Gen 2)
- 1x headphone / microphone combo jack (3.5mm)
- 1x microphone (3.5mm)
|
| Rear Ports |
- 2x USB-A (Hi-Speed USB / USB 2.0)
- 2x USB-A (USB 5Gbps / USB 3.2 Gen 1), one supports Smart Power On
- 1x HDMI® 2.1 TMDS
- 1x VGA
- 1x Ethernet (RJ-45)
- 1x line-out (3.5mm)
|
| Optional Rear Ports (configured) |
None
|
| SECURITY & PRIVACY |
| Security Chip |
Firmware TPM 2.0 integrated in SoC
|
| Physical Locks |
- Kensington Security Slot™, 3 x 7 mm
- Padlock Loop
|
| Smart Cable Clip |
None
|
| Additional Security |
None
|
| SERVICE |
| Base Warranty |
1-year, Courier or Carry-in
|
| Included Upgrade |
1Y Premier Support Upgrade from 1Y Courier/Carry-in
|
| SOFTWARE |
| Operating System |
None
|
| Bundled Software |
None
|
| ACCESSORIES |
| Bundled Accessories |
None
|
| MODEL INFORMATION |
| Model |
13K6000AVA
|
